These new Moisture Analyzers are ideal for routine moisture analysis requiring precise results. They combine high quality and durable construction into a sleek, compact design and offer dependable, accurate results for a wide variety of moisture analysis applications.
Feature | MB23ZH | MB25ZH | MB27ZH |
---|---|---|---|
Capacity | 110 g | 90 g | |
Repeatability (Std Dev) | 0.3% (3g sample) 0.2% (10g sample) |
0.2% (3g sample) 0.05% (10g sample) |
0.2% (3g sample) 0.05% (10g sample) |
Readability | 0.1%/0.01 g | 0.05%/0.005 g | 0.01%/0.001 g |
Sample Size | 3g to 20g typical, 0.5g min. | ||
Interface | Bidirectional RS-232 | ||
Timer | 1 – 99 minutes, 30-second increments to 60 minutes | ||
Heating Technology | Infrared (no glass) | Halogen | |
Temperature Range | 50°C to 160°C in 5°C increments | ||
Power | 100 to 240 VAC, 50/60 Hz | ||
Tare Range | To capacity by subtraction | ||
Operating Temp. Range | 5°C to 40°C | ||
Display Type | Custom backlit LCD | ||
Displays | % moisture or % solids or weight (g), temperature, time | ||
Pan Size (Diameter) | 90 mm | ||
Dimensions (W x H x D) | 17 cm x 13 cm x 28 cm | 17 cm x 14 cm x 28 cm | |
Net Weight | 2.1 kg | ||
Shipping Weight | 3.9 kg |
